Automatic Thermoforming Modified Atmosphere Packa | RFQ Sourcing Details

This automatic thermoforming modified atmosphere packaging machine is designed for solid food products such as frozen snacks, finger foods, prepared meals, meat, poultry, sausages, salami, seafood, bakery products, cheese, dried fruit and nuts. It uses separate top and bottom film rolls.

The bottom film is formed into an open container, after which the product is loaded and the package is vacuumed, gas flushed, sealed and cut into individual units. The stated workflow is automatic from package forming through finished-package output. Operation is managed through a 10-inch PLC touch screen.

Safety sensors are installed around covers, doors and other removable parts so the machine can stop when these areas are opened. Optional functions described for the system include date printing, automatic labeling and integration with third-party equipment.

Reference operating data includes 6–8 cycles per minute, forming depth up to 50 mm, film width up to 520 mm and advance length up to 500 mm. The listed machine dimensions are 6000 × 1100 × 1900 mm, with a weight of 2000 kg, a 1000 mm working height and a 2000 mm customizable loading area.

Listed power consumption is 18–25 kW. These figures are reference values and may change with the selected product, package and machine configuration. The referenced film specification is sealable PE/PA multilayer co-extruded plastic film.

Bottom film may be unprinted colored or transparent material, with a 500 mm roll diameter and thickness of at least 300 μm. Top film may be pre-printed or transparent, with a maximum 250 mm roll diameter and thickness up to 200 μm. The machine structure is listed as 304 stainless steel.

Before procurement, buyers should confirm the required package dimensions, daily production volume, product loading method, gas mixture and residual-oxygen target.

Film structure, forming depth, printed-film registration, labeling or date-coding requirements, utilities, line integration and the final achievable cycle rate should be validated against representative product and film samples.

Buyers should also obtain a configuration-specific drawing and confirm which components, safety provisions, installation services, spare parts and wear parts are included. A 12-month whole-machine warranty is stated, excluding wearable items such as silicone plates, film and heating elements.

Overseas engineering service is not included in that warranty. Online guidance, engineering support, installation and tuning services are described as available, but their precise scope, location, scheduling and commercial terms should be confirmed before ordering.
