Ots PLC Touch Laboratory Temperature Humidity Tes | RFQ Sourcing Details
Laboratory Instruments · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Product specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Laboratory Instruments. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Ots PLC Touch Laboratory Temperature Humidity Test Chamber Introduction: Test material heat, cold, dry resistance, humidity resistance.Suitable for electronics, electrical appliances,Communications, instrumentation, vehicles, plastic products, metal, food, chemical,building materials, medical, aerospaceand other products.
Specification: Model XB-OTS-80 XB-OTS-150 XB-OTS-225 XB-OTS-408 XB-OTS-800 XB-OTS-1000 Inner size W*H*DCM 40*50*40 50*60*50 50*75*60 60*85*80 100*100*800 100*100*100 External size W*H*DCM 90*143*100 100*153*110 110*168*110 130*178*120 150*193*140 150*193*160 Temperature range -70°C~+150°C(180°C) (A:-20°C B:-40°C C:-60°C D:-70°C ) Humidity range 20%~98%R.H.(10%-98%R.H/5%~98%R.H) Temp humidity analytic accuracy / uniformity ± 0.1°C;±0.1%R.H./ ±1.0°C;±3.0%R.H.is special optional condition.
Temperature humidity control accuracy/fluctuation ±1.0°C;±2.0%R.H./ ±0.5°C;±2.0%R.H. Heat/cooling time About 5.0°C/min;about 1.2°C/min (5~10°C/min is a special optional condition Inner and outer materials SUS#304 Stainless steel for inner chamber and Carton Advanced cold plate nano paint for outer.
Insulation materials Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials Cooling system Air cooling/single segment compressor(-20°C) ,air and water double segment compressor (-40°C~-70°C) Protection devices Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch, super humidity over-temperature protection switch, fuse, failure warning system Parts Watching window,50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze Controller TEMI" South Korea"TEMI" "OYO" Japan's "OYO" Brand optional Compressor Original France"Tecumseh"brand Power 1Φ 220VAC±10% 50/60.
Hz & 3Φ 380VAC±10% 50/60. Hz Features: *. High-texture appearance, the body adopted an arc shape, surface matte stripes processing, and flat-handle, easy to operate, safe and reliable . *.
Rectangular multi-layer glass View window, the use of guinea pigs observed in the test window witt anti-sweat heaters device prevents water gas condensate ,Knot, water droplets, PL fluorescent lamps to keep the inside lighting. *.
Door bunk isolated airtight packing, can be effectively isolated from the internal temperature of the leak *. With external water supply system, convenient to supplement the cylinder water supply, and automatic recovery using.
*.Compressor cycling system used France " Tecumseh " brand which can effectively remove condenser pipe and between capillary Lubricating oil and whole series adopt environmental protection refrigerant (R23, R404, R507) *. Controller uses the imported LED display screen, can display measured values and setting time *.
Controller with multisegment program editor and temperature and humidity can be fast (OUICK) or slope (SLOP) controlled. *.
Built-in Standard: GB/Bb T high temperature test method GB test A : low temperature test method 6 Ab IEC low temperature test method GJB test at low temperature EIA - 364-59 test at low temperature IEC temperature cycle IEC constant temperature IEC temperature cycle EIA - 364-31 C temp resistance GB/T2423.3 constant heat test method Certificate: Global safety design, use our chambers safely and with peace of mind for many years to come.
We deliver chambers that conform to international safety standards. Our chambers conform to ISO risk assessment as well as global safety design electrical safety standards such as CE marking and EMC directive. The production process of the test chambers : Our Services: We are here to help you.
Services available: Replacement manuals Consumables and replacement parts On-site maintenance and repair Warranty support Over-the
Ots | Applications and Buyer Notes
Ots is organized as a sourcing-ready Laboratory Instruments reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and lead-time questi
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- Laboratory InstrumentsBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- size
- W*H*DCM 40*50*40 50*60*50 50*75*60 60*85*80 100*100*800 100*100*100 ExternalBased on visible page data; confirm exact value in the RFQ.
- Power
- 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60HzBased on visible page data; confirm exact value in the RFQ.
- Warranty
- support Over-theBased on visible page data; confirm exact value in the RFQ.
- Specification
- Model XB-OTS-80 XB-OTS-150 XB-OTS-225 XB-OTS-408 XB-OTS-800 XB-OTS-1000 InnerBased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
Source mix: ugc
Key specifications
Product sourcing keywords
These terms come from the title, visible copy and specifications, and link into matching aggregate pages.
Continue from this detail page into sourcing structure
These links connect the detail page back to category hubs, procurement aggregates and knowledge pages so new inventory is not isolated.
This URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Procurement sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Cleanroom And Lab Furniture categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laboratory Instruments categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Sample Preparation And Consumables categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Testing And Measurement Equipment categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 10 98 Low Humidity Type Temperature Humidity Environmental Climate Test Chamber For Lab LaboratoThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 100l Pep De Synthesizer Technical SpecificationsThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 16500rpm High Speed Capillary Hematocrit Centrifuge For Hospital Medical Use Hematocrit CentrifugeThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 2 8 Degree Biomedical Vaccine Pharmacy Refrigerator Plasma Freezer For LabThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 2021 New Type Lab Centrifuge Xld900 1This URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 252l Programmable Three Zones Thermal Shock Test Machine Environmental Could And Hot Thermal TesterThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 3e Blood Harvest Prp Centrifuge Kit For Lab 3e Blood Harvest Prp Centrifuge Kit And Prp CentrifugeThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 3e Blood Harvest Prp Centrifuge Kit For LabThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Environmental Test Chamber Accelerated Aging Climate Machine Climatic Walk in Temperature Humidity TRequest Quote
Laboratory Stability Xenon Lamp Aging Test ChamberRequest Quote
Humidity Incubator, Constant Temperature Incubator, Laboratory Incubator, Humidity Biochemistry ChamRequest Quote
Laboratory Electric Heating Constant Temperature Incubator Smart Microbial Mold Static IncubatorRequest Quote
Touch Screen Laboratory Thermo Shaker Shaking Incubator - Shaker Incubator and Shaking IncubatorRequest Quote
Erun-Sp9-B6 High-Accuracy Turbidimeter Laboratory-Grade Tool for Industrial Water Quality TestingRequest QuoteLabInstSource related sourcing paths
