Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Labeling Machines. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Main features Introduction Rotary OPP hot melt glue adhesive labeling machine is the newest continuous operation of the labeling machine. The mainly used for container labeling cylindrical shape of detergents, beverages, mineral water, food etc. The material of label is using environmentally material of OPP films.
It can be automatically oxidative decomposition and reduce production costs by more than 30 percent. Labeling machine is control by PLC touch screen, all electric eye is using imported advanced configuration.
This labeling machine with high speed, high accuracy, stable performance, easy to operate and look elegant appearance. Technical Parameter model OPP-200R Number of rotary station 8 machine size 1800L*2640W*2100H(mm) weight 4.5T speed of labeling 15000BPH power AC 3ψ380V50.
Hz rater power 12KW percent of pass ≥99.5 accuracy of labeling ±1mm diameter of bottle 57mm material of bottle Glass, Metal, Plastic shape Round, Label material OPP,BOPP,PAPER Label thickness mm Label height 40mm-210mm inside diameter of paper tube 6inch power consumption of air source 0.5.
Mpa operation Automatically Details show Machine-Parameter 1. Body is built with stainless steel, steel construction stable and not rust 2. The whole machine used quick release type of construction. In order to change and adjustment easier. 3.
Centralized lubricating system for simple and effortless on maintenance, lubrication and cleanness. 4.With photo-sensors to detect label output and automatically self-regulated production speed for integrating production line with other machines 5. Used stable and reasonable of compiling program.
It can be suitable for operation 24 hours. 6.The bottle working mode is rotary Input and output type. 7. Equipped with the Torque limiter would control the torsion range abnormal situation of machine. It will reduce the accident for operate. 8. Roller coating, gluing balance and glue saving. 9.
Alarm system: Caution light & buzzer for out of label, Label break and door open! 10. Cut label system: Used multiple cure of cut system organization. (It is not quick-wear part) 11. The machine production speed is control by the machine input bottle signal. It is automatic transmission.
If input bottle stock, then the machine will be increase speed. If input bottle did not have bottle the machine will transmission speed slow. 12. The machine production speed is control by the machine input bottle signal. It is automatic transmission.
When the machine output bottle stock then the machine will be transmission speed to slow. If output bottle is smooth the machine will be increase the speed.
Machine Configuration 1 Fully enclosed Host: door stop 2 send bottles: Screw or star wheel 3 Feeding bottle: cylinder 4 Sperate bottle: Stars Wheel 5 Sending label: servo encoder control.
6 Illumination: LED, top + bottom access operation lamp lights + electrical control box overhaul lights 7 fixed feeding shelf: Removable standard planar fast.
(Optional double frame) 8 Touch screen: single touch 9 cabinet work: Column cabinet manually unscrew the formula 10 corrective devices: Germany E + L 11 Alarm system: warning light & buzzer, lack of material, marked off, open the door 12 Label system: Physical adjustable friction brake feed 13 Transmission systems: machine connections, independent label transmission
